T-17 minesweepers (projects 265, 265K, 265A, I265) (1954 - 1963)





1976

Ships


Name No Yard No Builder Laid down Launched Comp Fate Modification
T-2, 5.1966- БТ-2 [BT-2] (pr. 265A)     341 Yd, Rybinsk     1959-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-3, 5.1966- БТ-3 [BT-3] (pr. 265A)     341 Yd, Rybinsk     1959-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-17, 5.1966- БТ-17 [BT-17]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-19, 5.1966- БТ-19 [BT-19]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-23, 5.1966- БТ-23 [BT-23]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-24, 5.1966- БТ-24 [BT-24]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-25, 5.1966- БТ-25 [BT-25]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-26, 5.1966- БТ-26 [BT-26] (pr. 265A)   113 341 Yd, Rybinsk     1960 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-150, 5.1966- БТ-150 [BT-150]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-151, 5.1966- БТ-151 [BT-151] (pr. 265A)   125 341 Yd, Rybinsk     1960 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-152, 5.1966- БТ-152 [BT-152]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-153, 5.1966- БТ-153 [BT-153]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-156, 5.1966- БТ-156 [BT-156] (pr. 265A)     341 Yd, Rybinsk     12/1962 stricken 4.1990 Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-157, 5.1966- БТ-157 [BT-157]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-158, 5.1966- БТ-158 [BT-158]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-162, 5.1966- БТ-162 [BT-162] (pr. 265A)     341 Yd, Rybinsk     1959-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-164, 5.1966- БТ-164 [BT-164]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-165, 5.1966- БТ-165 [BT-165]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-166, 5.1966- БТ-166 [BT-166]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-167, 5.1966- БТ-167 [BT-167]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-172, 5.1966- БТ-172 [BT-172] (pr. 265A)     341 Yd, Rybinsk     1959-62 stricken 1984 Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-234, 5.1966- БТ-234 [BT-234]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-251, 5.1966- БТ-251 [BT-251]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-286, 5.1966- БТ-286 [BT-286]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-287, 5.1966- БТ-287 [BT-287]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-288, 5.1966- БТ-288 [BT-288]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-289, 5.1966- БТ-289 [BT-289]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-290, 5.1966- БТ-290 [BT-290]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-455, 5.1966- БТ-455 [BT-455]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-446, 5.1966- БТ-456 [BT-456]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-744, 5.1966- БТ-744 [BT-744]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-745, 5.1966- БТ-745 [BT-745]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-746, 5.1966- БТ-746 [BT-746]     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
T-...     341 Yd, Rybinsk     1954-62 stricken 1970s-80s Project 265 (2 ships), 265K (13 ships), 265A (24 ships)
TM-7     341 Yd, Rybinsk     1/1960 stricken 1970s-80s Project I265
TM-12     341 Yd, Rybinsk     1961 stricken 1970s-80s Project I265
TM-...     341 Yd, Rybinsk     1963 stricken 1970s-80s Project I265


Technical data


Displacement standard, t

pr. 265: 235

pr. 265K: 265

pr. 265A: 291

pr. I265: 285

Displacement full, t

pr. 265: 259

pr. 265K: 289

pr. 265A: 315

pr. I265: 303

Length, m

pr. 265: 44.6

pr. 265K: 46.1

pr. 265A, I265: 46.5

Breadth, m

pr. 265: 5.90

pr. 265K: 6.40

pr. 265A, I265: 6.60

Draught, m

pr. 265: 1.78

pr. 265K: 1.85

pr. 265A: 1.86

pr. I265: 1.84

No of shafts

2 Voith-Schneider

Machinery

pr. 265, 265K: 2 33D diesels

pr. 265A, I265: 2 36D diesels

Power, h. p.

pr. 265, 265K: 1800

pr. 265A, I265: 2000

Max speed, kts

pr. 265: 15.5

pr. 265K: 15

pr. 265A, I265: 14.5

Fuel, t

diesel oil

Endurance, nm(kts)

pr. 265, 265K: 1500(8)

pr. 265A, I265: 1500(10)

Armament

pr. 265: 1 x 2 - 37/70 V-11, 2 x 2 - 14.5/89, 1 DCT (10), 6 mines (obr. 1908/39), MT-3 mechanical, PEMT-4 magnetic, 2x BAT-2 acoustic minesweeping gear

pr. 265K: 1 x 1 - 45/89 SM-21ZIF, 2 x 2 - 25/112 2M-3M, 1 DCT (10), 6 mines (obr. 1908/39), MT-2 mechanical, PEMT-4 magnetic, BAT-2 acoustic minesweeping gear

pr. 265A: 1 x 1 - 45/89 SM-21ZIF (3 early ships) or 1 x 1 - 57/81 ZIF-71 (others), 2 x 2 - 25/112 2M-3M, 1 DCT (10), MT-2 mechanical, ST-2, PEMT-4 magnetic, AT-2 acoustic minesweeping gear

pr. I265: 1 x 1 - 57/81 ZIF-71, 2 x 2 - 25/112 2M-3M, 6 mines (obr. 1908/39), IT-3 USV

Electronic equipment

pr. 265, 265K, I265: Don radar, Tamir-11 sonar, Bizan'-4 ECM suite

pr. 265A: Don radar, MG-11-265A sonar, Bizan'-4 ECM suite

Complement

47



Standard scale images


<i>T-17 </i>1954
T-17 1954
<i>T-2 </i>1959
T-2 1959
<i>BT-172 </i>1980
BT-172 1980
<i>BT-156 </i>1979
BT-156 1979


Graphics


1976
1976


Project history

These steel coastal sweepers were built to place the wartime T-301 and the interim Project 255; they were also used as patrol craft. The TTZ was issued in 1946; it called for mine countermeasures up to 60nm from a base and also for minelaying. The main improvements, compared to Project 255, were a better sonar and better degaussing. On sea trials, the lead unit proved quite wet. In the improved Project 265K, the shape of the bow was changed, bilge keels were added. The next step 265A was to provide nuclear protection and also to increase engine power. Three ships were built as minehunters with IT-3 ROV.

Modernizations

None.

Naval service

In 1981 15 ships were in service, mostly stricken in 1980s. Only two served in 1992.
