BT-343 coastal minesweepers (project 12255) (1990)





RT-343 2008

Ships


Name No Yard No Builder Laid down Launched Comp Fate
БТ-343 [BT-343], 1992- РТ-343 [RT-343]   301 Sredne-Nevskiy SYd, Pontonnyy 9/1989 29.4.1990 22.12.1990 stricken 2012
-   302 Sredne-Nevskiy SYd, Pontonnyy 1989 --- --- suspended 1991
-   303 Sredne-Nevskiy SYd, Pontonnyy 1990 --- --- suspended 1991


Technical data


Displacement standard, t

72

Displacement full, t

80

Length, m

27.0

Breadth, m

3.90

Draught, m

2.10

No of shafts

1

Machinery

1 3D6SN-235 diesel

Power, h. p.

235

Max speed, kts

9

Fuel, t

diesel oil

Endurance, nm(kts)300(8)
Armament

1 x 1 Strela-3 SAM (4 9M36), 1 x 2 - 12.7/79, GKT-3M mechanical minesweeping gear

Electronic equipmentVaygach radar, Kozhimit-K drone control equipment
Complement

16



Standard scale images


<i>RT-343 </i> 2000
RT-343 2000


Graphics


<i>RT-343 </i>2008
RT-343 2008


Project history

Control ships for Project 13000 minesweeping drones.

Modernizations

None.

Naval service

No significant events.
