D-67 landing craft (project 11770) (1994-2014)





DKA-67 1996

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Д-67 [D-67] 767 801 Volga, Nizhniy Novgorod 7/1993 21.6.1994 12.1994 in service (2019)
Д-156 [D-156] 630 802 Volga, Nizhniy Novgorod     12.1999 in service (2019)
Д-131 [D-131] 631 803 Volga, Nizhniy Novgorod 1994   12.2002 in service (2019)
Д-172 [D-172] 645 804 Volga, Nizhniy Novgorod     12.2005 in service (2019)
Д-144 [D-144] 659 805 Volga, Nizhniy Novgorod     2.2008 in service (2019)
Д-56 [D-56] 634 806 Volga, Nizhniy Novgorod     12.2008 in service (2019)
Д-1441 [D-1441], 5.2010- Контр-адмирал Демидов [Kontr-admiral Demidov], 2018- Алексей Баринов [Alexey Barinov] 791 807 Volga, Nizhniy Novgorod     12.2009 in service (2019)
Д-1442 [D-1442], 5.2010- Контр-адмирал Оленин [Kontr-admiral Olenin], 2018- Иван Пасько [Ivan Pas'ko] 792 808 Volga, Nizhniy Novgorod     12.2009 in service (2019)
    809 Volga, Nizhniy Novgorod     5.2013 // --- completed mercantile?
    810 Volga, Nizhniy Novgorod   2012 5.2013 // --- completed mercantile?
Д-199 [D-199] 544 811 Volga, Nizhniy Novgorod   2012 8.2014 in service (2019)
Д-107 [D-107] 650 3001 Vostochnaya SYd, Vladivostok 12/2008 15.4.2010 6.2010 in service (2019)


100 - 1000 t displacement/ BRT tonnage vessels


Name No Yard No Builder Laid down Launched Comp Fate Д-67 [D-67] 767 801 Volga, Nizhniy Novgorod 7/1993 21.6.1994 12.1994 in service (2019) Д-156 [D-156] 630 802 Volga, Nizhniy Novgorod     12.1999 in service (2019) Д-131 [D-131] 631 803 Volga, Nizhniy Novgorod 1994   12.2002 in service (2019) Д-172 [D-172] 645 804 Volga, Nizhniy Novgorod     12.2005 in service (2019) Д-144 [D-144] 659 805 Volga, Nizhniy Novgorod     2.2008 in service (2019) Д-56 [D-56] 634 806 Volga, Nizhniy Novgorod     12.2008 in service (2019) Д-1441 [D-1441], 5.2010- Контр-адмирал Демидов [Kontr-admiral Demidov], 2018- Алексей Баринов [Alexey Barinov] 791 807 Volga, Nizhniy Novgorod     12.2009 in service (2019) Д-1442 [D-1442], 5.2010- Контр-адмирал Оленин [Kontr-admiral Olenin], 2018- Иван Пасько [Ivan Pas'ko] 792 808 Volga, Nizhniy Novgorod     12.2009 in service (2019)     809 Volga, Nizhniy Novgorod     5.2013 // --- completed mercantile?     810 Volga, Nizhniy Novgorod   2012 5.2013 // --- completed mercantile? Д-199 [D-199] 544 811 Volga, Nizhniy Novgorod   2012 8.2014 in service (2019) Д-107 [D-107] 650 3001 Vostochnaya SYd, Vladivostok 12/2008 15.4.2010 6.2010 in service (2019)

Technical data


Displacement standard, t

61

Displacement normal, t

100

Length, m

25.7

Breadth, m

5.66

Draught, m

1.52

No of shafts

2

Machinery

801-806, 3001: 2 M-503A-3 diesels

807-811: 2 MTU 16V2000M90 diesels

Power, h. p.

801-806, 3001: 6600

807-811: 4000

Max speed, kts

30

Fuel, t

diesel oil

Endurance, nm(kts)

600(12)

Armament

none

Military load

1 main battle tank or 2 APC or 92 troops or 50 t of cargo

Electronic equipment

Pal-N-3 radar

807: MR-231-2 radar

Complement

5



Standard scale images


<i>D-67 </i>2000
D-67 2000


Graphics


<i>DKA-67 </i>1996
DKA-67 1996


Project history

Private venture design by Central Hydrofoil Design Bureau. Have 13x4m cargo deck extending to 2m under pilot house, and articulating bow ramp. The semiplaning hull incorporates an air cavity to provide underhull lubrication. Aluminium alloy construction.

Modernizations

None.

Naval service

No significant events.
