Delfin 1979

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate	Modification
Дельфин [Delfin]		201	Gorkiy Yd, Zelenodolsk	21.4.1973	19.7.1975	31.12.1975	to Bulgaria 2.1991 (Смели [Smeli])	Project 1159
Нерпа [Nerpa]		202	Gorkiy Yd, Zelenodolsk	22.10.1974	4.6.1977	31.12.1977	to East Germany 7.1978 (Rostock)	Project 1159
Кречет [Krechet]		203	Gorkiy Yd, Zelenodolsk	19.1.1977	3.7.1978	31.12.1978	to East Germany 5.1979 (Berlin - Haupstadt der DDR)	Project 1159
Сокол [Sokol]		204	Gorkiy Yd, Zelenodolsk	1/1978	21.4.1979	30.11.1979	to Yugoslavia 3.1980 (Сплит [Split])	Project 1159
СКР-481 [SKR-481]		205	Gorkiy Yd, Zelenodolsk	25.12.1979	24.12.1981	30.9.1982	to Yugoslavia 12.1982 (Копер [Koper])	Project 1159
СКР-149 [SKR-149]		206	Gorkiy Yd, Zelenodolsk	8.4.1983	30.6.1984	25.6.1985	to East Germany 11.1985 (Halle)	Project 1159
СКР-482 [SKR-482]		250	Gorkiy Yd, Zelenodolsk	10.6.1978	12.1.1980	30.9.1980	to Algeria 12.1980 (مراد رئس [Mourad Rais])	Project 1159T
СКР-28 [SKR-28]		251	Gorkiy Yd, Zelenodolsk	17.7.1979	21.6.1980	30.12.1980	to Cuba 9.1981 (Mariel)	Project 1159T
СКР-35 [SKR-35]		252	Gorkiy Yd, Zelenodolsk	11.6.1980	30.4.1981	30.11.1981	to Algeria 3.1982 (رئس كلش [Rais Kellich])	Project 1159T
СКР-471 [SKR-471]		253	Gorkiy Yd, Zelenodolsk	24.4.1981	31.7.1982	17.8.1983	to Cuba 2.1984 (356)	Project 1159T
СКР-129 [SKR-129]		254	Gorkiy Yd, Zelenodolsk	7.7.1982	11.11.1983	30.8.1984	to Algeria 1.1985 (رئس قرف [Rais Korfu])	Project 1159T
СКР-451 [SKR-451]		257	Gorkiy Yd, Zelenodolsk	6.5.1986	3.5.1987	25.12.1987	to Cuba 4.1988 (Moncada)	Project 1159T
СКР-201 [SKR-201]		255	Gorkiy Yd, Zelenodolsk	22.9.1982	27.4.1985	30.12.1985	to Lybia 6.1986 (الهاني [Al Hani])	Project 1159TR
СКР-195 [SKR-195]		256	Gorkiy Yd, Zelenodolsk	18.4.1985	27.4.1986	25.12.1986	to Lybia 10.1987 (القيردبا [Al Kyrdabian])	Project 1159TR

Technical data

Displacement standard, t	pr. 1159: 1440 pr. 1159T: 1520 pr. 1159TR: 1550
Displacement normal, t	pr. 1159: 1660 pr. 1159T: 1673 pr. 1159TR: 1705
Length, m	96.5
Breadth, m	12.6
Draught, m	pr. 1159: 3.20 hull 5.57 max pr. 1159T: 3.32 hull 5.74 max pr. 1159TR: 3.28 hull 5.39 max
No of shafts	3
Machinery	pr. 1159, 1159T: 1 M-8G gas turbine (central shaft) + 2 68B diesels (outer shafts) pr. 1159TR: 1 M8V6 gas turbine (central shaft) + 2 68B-6 diesels (outer shafts)
Power, h. p.	20000 + 16000 = 36000
Max speed, kts	pr. 1159: 29.7 pr. 1159T: 29 pr. 1159TR: 28
Fuel, t	diesel oil
Endurance, nm(kts)	pr. 1159: 4500 (14) pr. 1159T: 4000(14) pr. 1159TR: 3800(14)
Armament	pr. 1159, 1159T: 1 x 2 Osa-M SAM (20 9M33), 2 x 2 - 76/59 AK-726, 2 x 2 - 30/71 AK-230, 2 x 12 RBU-6000 Smerch-2 ASWRL, 2 DCR (12), 14 mines pr. 1159TR: 2 x 2 P-20M Termit SSM (4 P-20M), 1 x 2 Osa-M SAM (20 9M33), 2 x 2 - 76/59 AK-726, 2 x 2 - 30/71 AK-230, 4 - 400 TT, 1 x 12 RBU-6000 Smerch-2 ASWRL, 2 DCR (12), 14 mines
Electronic equipment	MR-320 Topaz-2V, Fut-N, 4R-33, MR-105 Turel', MR-104 Rys', Don radars, MG-311 Vychegda sonar, Bizan'-4B ECM suite
Complement	pr. 1159, 1159T: 108 pr. 1159TR: 112

Standard scale images

Graphics

Project history

Small frigates built for export. Only Delfin was retained in the Soviet Navy for training of foreign crews and demonstration.

Modernizations

None.

Naval service

No significant events.
