ASTRAKHAN' large gun ships (project 21630) (2006 - 2012)





Astrakhan'                     Dmitriy Babichev, 2006

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Астрахань [Astrakhan'] 017 701 Almaz, St. Petersburg 30.1.2004 7.10.2005 1.9.2006 in service (2019)
Волгодонск [Volgodonsk] (ex-Каспийск [Kaspiysk]) 161 702 Almaz, St. Petersburg 25.2.2005 6.5.2011 20.12.2011 in service (2019)
Махачкала [Makhachkala] 020 703 Almaz, St. Petersburg 24.3.2006 27.4.2012 4.12.2012 in service (2019)


Technical data


Displacement standard, t500
Displacement full, t

550

Length, m

61.8

Breadth, m

10.3

Draught, m

3.00

No of shafts

2 waterjets

Machinery

2 M507D diesels

Power, h. p.

16000

Max speed, kts

26

Fuel, t

diesel oil

Endurance, nm(kts)

1500(14)

Armament

1 x 6 Gibka SAM (12 Igla-1M), 1 x 1 - 100/59 A-190-01, 2 x 6 - 30/54 AK-306, 2 x 1 - 14.5/89, 1 x 40 - 122 Grad-M rocket launcher

Electronic equipment

5P-26M Pozitiv-M, MR-231, 5P-10-03 Laska radars, 2x PK-10 Smelyy decoy launchers

Complement

48



Standard scale images


<i>Astrakhan' </i>2010
Astrakhan' 2010


Graphics


<i>Astrakhan'                     Dmitriy Babichev, 2006</i>
Astrakhan'                     Dmitriy Babichev, 2006


Project history

Buyan code name. Intended for coastal operations including fisheries and EEZ patrol. Additional planned units of the class were cancelled in favor of missile-armed Buyan-M.

Modernizations

None.

Naval service

No significant events.
