Admiral Ushakov

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Адмирал Ушаков [Admiral Ushakov]			Baltic Works, St. Petersburg	28.6.1892	8.11.1893	30.9.1897	sunk 28.5.1905
Адмирал Сенявин [Admiral Senyavin]			New Admiralty, St. Petersburg	1.8.1892	22.8.1894	15.7.1897	surrendered to Japanese 28.5.1905 (見島 [Mishima])
Генерал-адмирал Апраксин [General-admiral Apraksin]			New Admiralty, St. Petersburg	24.10.1894	12.5.1896	16.8.1899	surrendered to Japanese 28.5.1905 (沖ノ島 [Okinoshima])

Technical data

Displacement normal, t	Admiral Ushakov: 4648 Admiral Senyavin: 4792 General-admiral Apraksin: 4152
Displacement full, t
Length, m	81.9 pp 84.8 wl 86.4 oa
Breadth, m	15.9
Draught, m	5.70 - 6.10 max
No of shafts	2
Machinery	2 HTE, 4 cylindrical boilers
Power, h. p.	4250
Max speed, kts	Admiral Ushakov, Admiral Senyavin: 16 General-admiral Apraksin: 15
Fuel, t	coal 400
Endurance, nm(kts)	3000(9)
Armour, mm	Harvey; belt: 254 - 203, bulkheads: 203 - 152, turrets: 178, barbettes: 152, deck: 51 - 25, CT: 178
Armament	Admiral Ushakov, Admiral Senyavin: 2 x 2 - 254/43, 4 x 1 - 120/43 Canet, 2 x 1 - 63/17 Baranovski, 6 x 1 - 47/40 Hotchkiss, 18 x 1 - 37/20 Hotchkiss, 4 - 381 TT (aw, 1 bow, 2 beam, 1 stern) General-admiral Apraksin: 1 x 2 - 254/43, 1 x 1 - 254/43, 4 x 1 - 120/43 Canet, 2 x 1 - 63/17 Baranovski, 10 x 1 - 47/40 Hotchkiss, 12 x 1 - 37/20 Hotchkiss, 4 - 381 TT (aw, 1 bow, 2 beam, 1 stern)
Complement	406

Standard scale images

Graphics

Project history

Intended to match Swedish ships, and unsuited for the voyage half way round the world which ended at Tsushima. The 254mm guns were a lighter, lower fire rate than in the Peresvet class, and General-admiral Apraksin differed from the other two in having a one-gun after turret.

Ship protection

Main belt (53x2.1m) extended between the barbettes and was 254mm abreast machinery (tapered to 127mm at lower edge) and 203mm abreast barbettes, it was closed by 203mm fore and 152mm aft bulkheads. Armoured deck was 25mm flat over the belt and 51mm turtleback-formed at ship ends.

Modernizations

1904, all: - 2 - 381 TT (1 bow, 1 aft)

Naval service

All three ships were lost at the Battle of Tsushima 28.5.1905: Admiral Ushakow was sunk by gunfire of two Japanese armoured cruisers; Admiral Senyavin and General-admiral Apraksin surrendered to Japanese and after repair were commissioned by them as Mishima and Okinoshima respectively.
