Vulcano 1933

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Vulcano			Thornycroft, Southampton, UK		1910	1910	discarded late 1940s

Technical data

Displacement normal, t	151
Displacement full, t
Length, m	33.5
Breadth, m	5.90
Draught, m	1.30 normal 2.20 max
No of shafts	2
Machinery	2 VTE, 1 Thornycroft cylindrical boiler
Power, h. p.	412
Max speed, kts	12
Fuel, t	coal
Endurance, nm(kts)
Armament	mines
Complement	24

Standard scale images

Graphics

Project history

Small net- and a mine-layer. In 1920s-1930s she was employed for torpedo training and carried 3 torpedo tubes.

Modernizations

None.

Naval service

 No significant events.
