Zorza 1974

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Fala	301, 1968- 321, 9.1991- SG321		Stocznia Marynarki Wojennej, Gdynia			7/1965	Coast Guard 9.1991, stricken 6.1996
Szkwał	302, 1968- 322, 9.1991- SG322		Stocznia Marynarki Wojennej, Gdynia			9/1966	Coast Guard 9.1991, stricken 9.1997
Zefir	303, 1968- 323, 9.1991- SG323		Stocznia Marynarki Wojennej, Gdynia			6/1967	Coast Guard 9.1991, stricken 6.2006
Zorza	324, 9.1991- SG324		Stocznia Marynarki Wojennej, Gdynia			1/1968	Coast Guard 9.1991, stricken 4.1999
Tęcza	325, 9.1991- SG325		Stocznia Marynarki Wojennej, Gdynia			1/1968	Coast Guard 9.1991, stricken 3.2008

Technical data

Displacement standard, t	212
Displacement full, t	237
Length, m	41.3
Breadth, m	6.29
Draught, m	1.95
No of shafts	2
Machinery	2 40DM diesels
Power, h. p.	5000
Max speed, kts	24.9
Fuel, t	diesel oil
Endurance, nm(kts)	1200(16)
Armament	2 x 2 - 30/71 AK-230, 2 DCR (12) or 4 mines
Electronic equipment	SRN-231 radar, Tamir-2 sonar
Complement	20

Standard scale images

Graphics

Project history

Polish Project 912. Developed from the 'Gdansk' class with steel hulls and aluminium alloy deckhouses. Intended for patrol duties.

Modernizations

None.

Naval service

No significant events.
