Górnik 2002 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Górnik (ex-R-624)	434	01711	Vympel, Rybinsk, USSR			1983 // 28.12.1983	stricken 5.2005
Hutnik (ex-R-62)	435	01712	Vympel, Rybinsk, USSR			1983 // 31.3.1984	stricken 5.2005
Metalowiec (ex-R-542)	436	01720	Vympel, Rybinsk, USSR			1987 // 13.2.1988	stricken 12.2013
Rolnik (ex-R-833)	437	01722	Vympel, Rybinsk, USSR			1988 // 4.2.1989	stricken 12.2013

Technical data

Displacement standard, t	385
Displacement full, t	455
Length, m	49.5 pp 56.1 oa
Breadth, m	10.2
Draught, m	2.20 hull 3.59 propellers
No of shafts	2
Machinery	2 M-15E gas turbine units (each consist of M-75 cruising gas turbine and M-70 boost gas turbine)
Power, h. p.	10000 + 24000 = 34000
Max speed, kts	43
Fuel, t	diesel oil 50
Endurance, nm(kts)	2200(14)
Armament	2 x 2 P-20M Termit SSM (4 P-20M), 1 x 4 Strela-2M SAM (16 9M32M), 1 x 1 - 76/59 AK-176M, 2 x 6 - 30/54 AK-630M
Electronic equipment	434, 435: Garpun-E, MR-123 Vympel-A, Kivach-2 radars, 2x PK-16 decoy RL 436, 437: Garpun-E, MR-123 Vympel-A, Pechora-1 radars, 2x PK-16 decoy RL
Complement	37

Standard scale images

Graphics

Project history

Soviet project 1241RE export version of project 1241T/12411.

Modernizations

None.

Naval service

No significant events.
