Emilio Jacinto 2011 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Emilio Jacinto (ex-Peacock)	PS35	988	Hall Russell, Aberdeen, UK	29.1.1982	1.12.1982	12.10.1983 // 1.8.1997	in service (2019)
Apolinario Mabini (ex-Plover)	PS36	989	Hall Russell, Aberdeen, UK	13.5.1982	12.4.1983	20.7.1984 // 1.8.1997	in service (2019)
Artemio Ricarte (ex-Starling)	PS37	990	Hall Russell, Aberdeen, UK	9.9.1982	7.9.1983	10.8.1984 // 1.8.1997	in service (2019)

Technical data

Displacement standard, t	662
Displacement full, t	712
Length, m	60.0 pp 62.6 oa
Breadth, m	10.0
Draught, m	2.72
No of shafts	2
Machinery	2 APE-Crossley-SEMT-Pielstick 18PA6 V280 diesels
Power, h. p.	14188
Max speed, kts	28
Fuel, t	diesel oil 44
Endurance, nm(kts)	2500(17)
Armament	1 x 1 - 76/62 OTO Melara Compact, 4 x 1 - 7.6/90, 2 x 1 - 50 flare rocket launchers
Electronic equipment	type 1006 radar, GSA.7 Sea Archer E/O director
Complement	31

Standard scale images

Graphics

Project history

Former RN Peacock class patrols built for service in Hong Kong waters.

Modernizations

2005-2006, all: - 4 x 1 - 7.6/90, 2 x 1 - 50 flare rocket launchers, type 1006 radar, GSA.7 Sea Archer e/o system; + 1 x 1 - 25/75 DS-25, 2 x 1 - 12.7/90, Sperry Bridgemaster radar, Radamec 1500 e/o system

Naval service

No significant events.
