  Bienvenido Salting 1996

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Tomas Batillo (ex-Gireogi 225)	PG110		Korea Tacoma, Chinhae, South Korea			early 1980s // 15.6.1995	foundered 8.1.2003, salvaged, CTL
Boni Serrano (ex-Gireogi 226)	PG111		Korea Tacoma, Chinhae, South Korea			early 1980s // 15.6.1995	in service (2019)
Bienvenido Salting (ex-Gireogi 229)	PG112		Korea Tacoma, Chinhae, South Korea			early 1980s // 15.6.1995	stricken 10.2018
Salvador Abcede (ex-Gireogi 231)	PG114		Korea Tacoma, Chinhae, South Korea			early 1980s // 15.6.1995	in service (2019)
Ramon Aguirre (ex-Gireogi 235)	PG115		Korea Tacoma, Chinhae, South Korea			early 1980s // 15.6.1995	damaged during delivery 6.1995, never commissioned
Nicolas Mahusay (ex-Gireogi...)	PG116		Korea Tacoma, Chinhae, South Korea			early 1980s // 1998	in service (2019)
Dionisio Ojeda (ex-Gireogi 232)	PG117		Korea Tacoma, Chinhae, South Korea			early 1980s // 7.12.2006	stricken 2018
Emilio Liwanag (ex-Gireogi 223)	PG118		Korea Tacoma, Chinhae, South Korea			early 1980s // 4.1.2011	in service (2019)

Technical data

Displacement standard, t	113
Displacement full, t	143
Length, m	31.3 wl 33.1 oa
Breadth, m	6.92
Draught, m	1.75 hull 2.45 propellers
No of shafts	2
Machinery	2 MTU 16V538 TB90 diesels
Power, h. p.	10800
Max speed, kts	38
Fuel, t	diesel oil 15
Endurance, nm(kts)	1000(20)
Armament	PG110, 111, 112, 115, 116, 118: 1 x 1 - 40/60 Mk 3, 1 x 2 - 30/75 Emerlec EX-30, 2 x 1 - 20/70 Mk 10 PG114, 117: 1 x 1 - 40/60 Mk 3, 2 x 1 - 20/90 Mk 10, 4 x 1 - 12.7/90, 2 x 1 - 7.6/90
Electronic equipment	Raytheon 1645 radar
Complement	31

Standard scale images

Graphics

Project history

Former South Korean 'Sea Dolphin' class (PKM200) craft.

Modernizations

None.

Naval service

: No significant events.
