Hurmat 2008

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
حشمت [Hashmat] (ex-Astrant)	S135		Dubigeon, Nantes, France	15.9.1976	14.12.1977	17.2.1979	in service (2019)
حرمت [Hurmat] (ex-Adventurous)	S136		Dubigeon, Nantes, France	18.9.1977	1.12.1978	18.2.1980	in service (2019)

Technical data

Displacement standard, t	1230
Displacement normal, t	1450 / 1725
Length, m	67.6
Breadth, m	6.80
Draught, m	5.40
No of shafts	1
Machinery	2 SEMT-Pielstick 16PA4 V185 diesel-generators, 1 Schneider electric motor / 1 cruising electric motor
Power, h. p.	4600 / 4600 / 23
Max speed, kts	12.5 / 20
Fuel, t	diesel oil 200
Endurance, nm(kts)	8500(9) (snorkel) / 350(3.5)
Armament	4 - 533 TT (bow, 20 F17P)
Electronic equipment	DRUA-33 radar, DUUA-2A/B, DSUV-2H, DUUX-2A sonars, ARUR, ARUD ECM suites, DLA D3 CCS
Complement	55
Diving depth operational, m	300

Standard scale images

Graphics

Project history

French Agosta 70 class submarines from the South African order, cancelled after UN embargo declaration and bought by Pakistan in November 1978.

Modernizations

1985-1989, both: + ability to launch Sub-Harpoon SSM (4 UGM-84A instead of torpedoes); missiles were never transferred to Pakistan

mid-2010s, both: - DSUV-2H, DUUX-2A sonars, ARUR, ARUD ECM suites; + TSM 2233D, TSM 2933D sonars, DR-3000 ECM suite

Naval service

No significant events.
