1977

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
کوئٹہ [Quetta]	P141		Wuzhou SY, China			1963-1972 // 1972	MSA 1.1987, stricken 1990
لاہور [Lahore]	P142		Wuzhou SY, China			1963-1972 // 1972	stricken 1995
مرادن [Mardan], 4.1992- سبقت [Sabqat]	P143, 4.1992- P66		Wuzhou SY, China			1963-1972 // 1972	MSA 4.1992, stricken 2010
جویلجیت [Guilgit]	P144		Wuzhou SY, China			1963-1972 // 1972	stricken 1996
پیشین [Pishin]	P145, 1998- P65		Wuzhou SY, China			1963-1972 // 1972	MSA 1998, stricken 2005
سکھر [Sukkur]	P147		Wuzhou SY, China			1963-1972 // 1972	stricken 1995
سیحوان [Sehwan], 4.1992- رفاقت [Rafaqat]	P148, 4.1992- P68		Wuzhou SY, China			1963-1972 // 1972	MSA 4.1992, stricken 2010
بہاولپور [Bahawalpur]	P149, 1998- P69		Wuzhou SY, China			1963-1972 // 1972	MSA 1998, stricken 2005
بانوم [Banum]	P154		Wuzhou SY, China			1963-1973 // 1973	MSA 1.1987, stricken 1990
کالت [Kalat]	P156		Wuzhou SY, China			1963-1973 // 1973	MSA 1.1987, stricken 1990
لاڑکانہ [Larkana]	P159		Wuzhou SY, China			1963-1973 // 1973	stricken 1990
ساہیوال [Sahiwal]	P160		Wuzhou SY, China			1963-1973 // 1973	MSA 1.1987, stricken 1990

Technical data

Displacement standard, t	123
Displacement full, t	135
Length, m	38.8
Breadth, m	5.41
Draught, m	1.55
No of shafts	4
Machinery	2 M-50F-4 diesels, 2 12D6 diesels
Power, h. p.	4200 (2x1200+2x910)
Max speed, kts	28.5
Fuel, t	diesel oil
Endurance, nm(kts)	750(16.5)
Armament	2 x 2 - 37/63 type 74, 2 x 2 - 25/80 type 61M, 10 mines (overload)
Electronic equipment	Reya radar
Complement	36

Standard scale images

Graphics

Project history

Former Chinese type 062 (Shanghai-II) boats.

Modernizations

1987, Quetta, Banum, Kalat, Sahiwal; 1992, Sabqat, Rafaqat; 1998, Pishin, Bahawalpur: - Reya radar; + ARC-32A radar

Naval service

No significant events.
