Jalalat 1983

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P1021 ہیبت [Haibat] P1022 جلالت [Jalalat] P1023 جُرات  [Jurat] P1024 شجاعت [Shujaat]	Wuhu SY, China or Chuangxin SY, China: P1021-1024	1965-1976 // 10.1981: P1021, 1022 1965-1976 // 5.1982: P1023, 1024	none	none	1997: P1022 1998: P1021, 1023, 1024

Technical data

Displacement standard, t	68
Displacement full, t	74
Length, m	27.0
Breadth, m	6.50
Draught, m	1.30 mean hull 1.80 propellers
No of shafts	4
Machinery	4 M50F-4 (L-12V-180) diesels
Power, h. p.	4800
Max speed, kts	37
Fuel, t	diesel oil
Endurance, nm(kts)	500(24)
Armament	2 x 1 C-201 SSM (2 HY-2), 1 x 2 - 25/80 type 61
Electronic equipment	type 352 radar
Complement	17

Standard scale images

Graphics

Project history

Former Chinese type 024 boats, derivatives of Russian project 183R. Wooden hull.

Modernizations

None.

Naval service

No significant events.
