Ever Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Ever		270	Mitchell, Low Walker, UK	11.1871	15.10.1872	9.1873	TS 1884, accommodation ship 8.1914
Hydra		271	Mitchell, Low Walker, UK	11.1871	17.10.1872	9.1873	stricken 1906
Das			Rijkswerf, Amsterdam		1876	1876	minelayer 1914, sold 1925
Daak			Rijkswerf, Amsterdam		1874	1874	subsidiary service 1894
Fret			Rijkswerf, Amsterdam		1876	1876	accommodation ship 1898
Geep			Rijkswerf, Amsterdam		1875	1875	auxiliary 1908
Gier			Rijkswerf, Amsterdam		1875	1875	TS 1894, sold 1913
Havik			Rijkswerf, Amsterdam		1874	1874	minelayer 1914, BU 1936
Raaf			Rijkswerf, Amsterdam		1875	1875	subsidiary service 1894
Brak		92	Nederlandsche, Rotterdam		1875	1875	hulk 1902
Lynx, 1912- Los			Nederlandsche, Rotterdam	7.1874	20.5.1875	1875	sold 1925
Vos			Nederlandsche, Rotterdam		1875	1875	stricken 1893
Bever			Christie, Nolet & De Kuyper, Delfshaven		1876	1876	accommodation ship 1896
Sperwer			Christie, Nolet & De Kuyper, Delfshaven		1875	1875	TS 1896, auxiliary 1927

Technical data

Displacement normal, t	218
Displacement full, t	221
Length, m	25.9
Breadth, m	8.00
Draught, m	2.20
No of shafts	1
Machinery	1 VC, 2 cylindrical boilers
Power, h. p.	124 - 146
Max speed, kts	7.5 - 8
Fuel, t	coal 20
Endurance, nm(kts)	800(6)
Armament	1 x 1 - 229/14 Armstrong 12.5-ton MLR
Complement	34

Standard scale images

Graphics

Project history

Iron-hulled Rendell type gunboats.

Modernizations

1890s, all survived: - 1 x 1 - 229/14; + 1 x 1 - 209/32 Krupp No.1, 2 x 1 - 37/20 Hotchkiss, 1 x 5 - 37/17 Hothckiss

1914, Das, Havik: as minelayers were armed with 2 x 1 - 37/20 Hotchkiss, 1 x 1 - 7.9/80, mines

Naval service

No significant events.
