NAVYPEDIA


Mayu

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Fal, 1.1948- မူး [Mayu] (ex-Fal)	K266, 1950- F266		Smiths Dock, South Bank, UK	5/1942	9.11.1942	7.1943 // 25.5.1947	stricken 9.1979

Technical data

Displacement standard, t	1460
Displacement full, t	2170
Length, m	86.3 pp 91.8 oa
Breadth, m	11.2
Draught, m	3.70 deep load
No of shafts	2
Machinery	2 VTE, 2 Admiralty 3-drum boilers
Power, h. p.	5500
Max speed, kts	20
Fuel, t	oil 646
Endurance, nm(kts)
Armament	2 x 1 - 102/40 CP Mk XXIII, 6 x 1 - 40/60 Mk III, 1 x 24 - 178 Hedgehog Mk 10 ASWRL, 8 DCT, 2 DCR (150)
Electronic equipment	type 271 or type 272, type 291 or type 277 radars, type 144 sonar
Complement	140

Standard scale images

Graphics

Project history

RN 'River' class frigate acquired by Burma Royal Naval Volunteer Reserve 25.5.1947. She became a flagship of independent Burmese Navy 4.1.1948 and 29.8.1948 was permanently transferred to Burma.

Modernizations

late 1950s: - 1 x 1 - 102/40, 2 x 1 - 40/60, 1 x 24 - 178 Hedgehog ASWRL, 8 DCT, 2 DCR, type 144 sonar

Naval service

No significant events.
