NAVYPEDIA


Inya 1980

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
အင်းတော် [Indaw]	55		Danyard AS, Frederikshavn, Denmark			30.5.1980	in service (2019)
အင်း [Inma]	56		Danyard AS, Frederikshavn, Denmark			12.1981	sunk 1987
အင်းလျား [Inya]	57		Danyard AS, Frederikshavn, Denmark			25.3.1982	in service (2019)

Technical data

Displacement standard, t	385
Displacement full, t	506
Length, m	45.8 pp 50.0 oa
Breadth, m	10.5
Draught, m	2.75
No of shafts	2
Machinery	2 Burmeister & Wain 16V23L-VO diesels
Power, h. p.	4600
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)	4500(16)
Armament	55: 1 x 1 - 40/70 Breda-Bofors 564, 2 x 1 - 20/70 Mk 10, 1 helicopter (light) 56, 57: 1 x 1 - 40/70 Breda-Bofors 564, 2 x 1 - 20/70 Mk 10, helicopter deck
Electronic equipment	radar
Complement	20

Graphics

Project history

Ordered in Denmark in 1978, identical with Danish Havørnen. Mercantile design of helicopter-carrying small fishery protection vessel. Carry a David Still 25kt boarding boat in an inclined ramp at the stern. Sailed by the navy for the People's Pearl and Fishery Department.

Modernizations

None.

Naval service

Inma sank by unknown reason in 1987.
