Regulus 2005

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
PI1101 Polaris PI1102 Sirius PI1103 Capella PI1104 Canopus PI1105 Vega PI1106 Achernar PI1107 Rigel PI1108 Arcturus PI1109 Alpheratz PI1110 Procyon PI1111 Avior PI1112 Deneb PI1113 Fomalhaut PI1114 Pollux PI1115 Regulus PI1116 Acrux PI1117 Spica PI1118 Hadar PI1119 Shaula PI1120 Mirfak PI1121 Ankaa PI1122 Bellatrix PI1123 Elnath PI1124 Alnilan PI1125 Peacock PI1126 Betelgeuse PI1127 Adhara PI1128 Alioth PI1129 Rosalhague PI1130 Nunki PI1131 Hamal PI1132 Suhail PI1133 Dubhe PI1134 Denebola PI1135 Alkaid PI1136 Alphecca PI1137 Eltanin PI1138 Cochab PI1139 Enif PI1140 Shedar PI1141 Markab PI1142 Megrez PI1143 Mizar PI1144 Phekda PI1145 Acamar PI1146 Diphda PI1147 Menkar PI1148 Sabik	Gotlands Varvet, Djupviks, Sweden: PI1101-1116 Docksravarvet, Docksta, Sweden: PI1117-1140 Astimar, Coatzacualcos: PI1141-1148	2000: PI1101-1125 2001: PI1126-1140 2004: PI1141-1148	None	None	in service (2019): PI1101-1148

Technical data

Displacement standard, t	13
Displacement full, t	20
Length, m	13.0 pp 16.1 oa
Breadth, m	3.80
Draught, m	1.00
No of shafts	2 waterjets
Machinery	2 Caterpillar 3406E diesels
Power, h. p.	1600
Max speed, kts	47
Fuel, t	diesel oil 1.5
Endurance, nm(kts)	250(30)
Armament	1 x 1 - 12.7/90
Electronic equipment	Bridgemaster E radar
Complement	3 + 18 troops

Graphics

Project history

Stridsbåt 90H design. Intended to combat smugglers (PI means Patrulla Interceptora). Aluminium construction, bow ramp for disembarkation.

Modernizations

None.

Naval service

No significant events.
