Miaplacidus 2005

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
PI1401 Miaplacidus PI1402 Algol PI1403 Castor PI1404 Merak PI1405 Caph PI1406 Mirach PI1407 Alhena PI1408 Saiph PI1409 Algorab PI1410 Albireo PI1411 Alnitak PI1412 Mintaka PI1413 Alfirk PI1414 Alderamin PI1415 Menkalinan PI1416 Circini PI1417 Gienah	Docksravarvet, Docksta, Sweden: PI1401 Astimar, Coatzacualcos: PI1402-1417	2005: PI1401 2006: PI1402-1409, 1411-1413, 1415, 1416 2012: PI1410, 1414 2015: PI1417	None	None	in service (2019): PI1401-1417

Technical data

Displacement standard, t
Displacement full, t	19
Length, m	15.9 pp 17.6 oa
Breadth, m	3.80
Draught, m	1.10
No of shafts	2 waterjets
Machinery	2 MAN diesels
Power, h. p.	2200
Max speed, kts	50
Fuel, t	diesel oil
Endurance, nm(kts)	240(30)
Armament	1 x 1 - 12.7/90
Electronic equipment	Bridgemaster E radar
Complement	4 + 18 troops

Graphics

Project history

Modified Stridsbåt 90H design, often named as Polaris II class. Intended to combat smugglers (PI means Patrulla Interceptora). Aluminium construction, bow ramp for disembarkation.

Modernizations

None.

Naval service

No significant events.
