Dar el Barka 1980

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
PCR321 تشت [Tichitt] PCR322 در إل بربا [Dar El Barba]	CN de l'Esterel, Cannes, France: PCR321, 322	4-9/1969: PCR321, 322	none	none	1998: PCR321, 322

Technical data

Displacement standard, t	75
Displacement full, t	80
Length, m	32.0
Breadth, m	5.75
Draught, m	1.70
No of shafts	2
Machinery	2 MTU-Mercedes-Benz MB820Db/h diesels
Power, h. p.	2700
Max speed, kts	28
Fuel, t	diesel oil
Endurance, nm(kts)	1500(15)
Armament	2 x 1 - 20/70 Mk 7
Electronic equipment	radar
Complement	17

Standard scale images

Graphics

Project history

Patrol craft, wooden hull.

Modernizations

1990s, both: - 2 x 1 - 20/70; + 1 x 1 - 12.7/90

Naval service

No significant events.
