Ras AL Hani 1988

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
راس الجليس [Ras El Gelais], 1983- الاقصر [Al I'sar] (ex-Марсовой [Marsovoy])	M111, 1983- 111		Sredne-Nevskiy, Pontonnyy, USSR			1980 // 3.1981	abandoned 2011
راس حداد [Ras Hadad], 1983- التيار [Al Tayyar]	M113, 1983- 113		Sredne-Nevskiy, Pontonnyy, USSR			1980 // 3.1981	abandoned 2011
راس الحمن [Ras Al Hamman]	115		Sredne-Nevskiy, Pontonnyy, USSR			1982 // 2.1983	hulk 1998
راس الفلوجة [Ras Al Falluga]	117		Sredne-Nevskiy, Pontonnyy, USSR			1982 // 2.1983	in service (2019)
راس الأولى [Ras Al Oula]	119	862	Sredne-Nevskiy, Pontonnyy, USSR			1983 // 3.9.1983	in service (2019)
راس الدور [Ras Al Dawar]	121	863	Sredne-Nevskiy, Pontonnyy, USSR			1983 // 2.1984	hulk 1998
راس مسعد [Ras Massad]	123	864	Sredne-Nevskiy, Pontonnyy, USSR			1983 // 12.1984	foundered 2013
راس الهاني [Ras Al Hani] (ex-MT-76)	125	865	Sredne-Nevskiy, Pontonnyy, USSR			1985 // 7.1986	hulk 1998

Technical data

Displacement standard, t	750
Displacement full, t	804
Length, m	61.0
Breadth, m	10.2
Draught, m	2.30
No of shafts	2
Machinery	2 M-503B-37 diesels
Power, h. p.	5000
Max speed, kts	16
Fuel, t	diesel oil
Endurance, nm(kts)	3000(12)
Armament	2 x 1 Igla-1 SAM (20 9M313), 2 x 2 - 30/71 AK-230M, 2 x 2 - 25/112 2M-3M, 2 x 5 RBU-1200M Uragan ASWRL, 2 DCR (32) or 8 UDE mines, GKT mechanical, TEM-3 magnetic, AT-2 acoustic minesweeping gear, ShZ-1 or ShZ-2 mine clearance line charges
Electronic equipment	MR-212 Vaygach, MR-104 Rys' radars, MG-69 Lan', MG-79 Mezen' sonars
Complement	69

Standard scale images

Graphics

Project history

Soviet export project 266ME.

Modernizations

None.

Naval service

No significant events.
