Mulkae 76 1987

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
물크 72 [Mulkae 72]	72		Hanjin, Masan			6.1978	stricken late 2000s
물크 73 [Mulkae 73]	73		Hanjin, Masan			6.1978	stricken late 2000s
물크 75 [Mulkae 75]	75		Hanjin, Masan			6.1978	stricken late 2000s
물크 76 [Mulkae 76]	76		Hanjin, Masan			1980	stricken late 2000s
물크 77 [Mulkae 77]	77		Hanjin, Masan			1981	stricken late 2000s
물크 78 [Mulkae 78]	78		Hanjin, Masan			1981	stricken 2014, to Philippines 7.2015
물크 79 [Mulkae 79]	79		Hanjin, Masan			30.9.1997	stricken 2010s
물크 81 [Mulkae 81]	81		Hanjin, Masan			31.10.1997	stricken 2018
물크 82 [Mulkae 82]	82		Hanjin, Masan			31.11.1997	stricken 2018
물크 83 [Mulkae 83]	83		Hanjin, Masan			late 2000s	in service (2019)
물크 85 [Mulkae 85]	85		Hanjin, Masan			late 2000s	in service (2019)
물크 86 [Mulkae 86]	86		Hanjin, Masan		20.10.2010	24.2.2011	in service (2019)

Technical data

Displacement standard, t	220
Displacement full, t	415
Length, m	41.1
Breadth, m	9.07
Draught, m	2.08
No of shafts	2
Machinery	4 General Motors 6-71 diesels
Power, h. p.	1200
Max speed, kts	12
Fuel, t	diesel oil
Endurance, nm(kts)	560(11)
Armament	2 x 1 - 20/70 Mk 10
Military load	143 t cargo
Electronic equipment	radar
Complement	14

Graphics

Project history

Korean copies of US LCU1610 with a higher piloyhouse.

Modernizations

None.

Naval service

No significant events.
