Cheonmasan 1989

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
해울 28 북한산 [Haeul 28 Bukhansan]	278		Hyundai, Ulsan			1989	in service (2019)
해울 29 천마산 [Haeul 29 Cheonmasan]	279		Hyundai, Ulsan			1989	in service (2019)
해울 31 [Haeul 31]	281		Hyundai, Ulsan			1990	stricken 2013
해울 32 [Haeul 32]	282		Hyundai, Ulsan			1990	stricken 2013

Technical data

Displacement standard, t	350
Displacement full, t	380
Length, m	47.8 pp 53.1 oa
Breadth, m	7.10
Draught, m	2.40
No of shafts	2
Machinery	2 MTU diesels
Power, h. p.	8300
Max speed, kts	28
Fuel, t	diesel oil
Endurance, nm(kts)	2500(15)
Armament	278: 1 x 2 - 40/70 Breda-Bofors Compact Twin 40, 1 x 3 - 20/76 Sea Vulcan, 2 x 1 - 12.7/90 279, 281, 282: 1 x 1 - 40/70 Bofors ADI315, 1 x 3 - 20/76 Sea Vulcan, 2 x 1 - 12.7/90
Electronic equipment	radar, e/o system
Complement	35

Graphics

Project history

Development of the Sea Wolf/Sea Shark (Haeul 521) series. DW300P design.

Modernizations

None.

Naval service

No significant events.
