PK182 1982

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
151 - 153 남학생 51-53 [Haksaeng 51 - 53] 155 - 159 남학생 55-59 [Haksaeng 55 - 59] 161 - 163 남학생 61-63 [Haksaeng 61 - 63] 165 - 169 남학생 65-69 [Haksaeng 65 - 69] 171 - 173 남학생 71-73 [Haksaeng 71 - 73] 175 - 179 남학생 75-79 [Haksaeng 75 - 79] 181 - 183 남학생 81-83 [Haksaeng 81 - 83] 185 - 189 남학생 85-89 [Haksaeng 85 - 89]	Korea SB, Pusan: 151 - 153, 155 - 159, 161 - 163, 165 - 169, 171 - 173, 175 - 179, 181 - 183, 185 - 189	1975-1978: 151 - 153, 155 - 159, 161 - 163, 165 - 169, 171 - 173, 175 - 179, 181 - 183, 185 - 189	none	none	late 1990s: 151 - 153, 155 - 159, 161 - 163, 165 - 169, 171 - 173, 175 - 179, 181 - 183, 185 - 189

Technical data

Displacement standard, t	70
Displacement full, t	78
Length, m	25.7
Breadth, m	5.40
Draught, m	1.20
No of shafts	2
Machinery	2 MTU 16V538 TD90 diesels
Power, h. p.	5200
Max speed, kts	40
Fuel, t	diesel oil
Endurance, nm(kts)	500(20)
Armament	earlier: 1 x 1 - 40/60 Mk 3, 1 x 1 - 20/70 Mk 10, 2 x 2 - 12.7/90 later: 1 x 1 - 40/60 Daewoo ADS, 3 x 2 - 12.7/90
Electronic equipment	radar
Complement	25

Graphics

Project history

Small patrol boats. Armament varied.

Modernizations

None.

Naval service

No significant events.
