project 613 submarines (1953-1956/1963-1966)







Ships


Name No Yard No Builder Laid down Launched Comp Fate
(i) (ex-S-75)     444 Marti Yd, Nikolayev, USSR 31.3.1953 8.8.1953 14.12.1953 // 3.1963 hulk 2003/05
(ii) (ex-S-90)     444 Marti Yd, Nikolayev, USSR 12.11.1953 31.12.1953 22.9.1954 // 3.1963 hulk 2003/05
(iii) (ex-S-325)     112 Zhdanov Yd, Gorkiy, USSR 23.7.1955 29.11.1955 17.8.1956 // 6.1966 hulk 2003/05
(iv) (ex-S-326)     112 Zhdanov Yd, Gorkiy, USSR 31.7.1955 24.12.1955 19.7.1956 // 6.1966 hulk 2003/05


Technical data


Displacement standard, t



Displacement normal, t

1045 / 1342

Length, m

76.0

Breadth, m

6.30

Draught, m

4.55

No of shafts

2

Machinery

2 37D diesels / 2 PG-101 electric motors

Power, h. p.

4000 / 2700

Max speed, kts

18.3 / 13.1

Fuel, t

diesel oil

Endurance, nm(kts)

8580(10) / 353(2)

Armament

6 - 533 TT (4 bow, 2 stern, 12 or 22 mines)

Electronic equipment

Flag radar, Tamir-5L, Feniks sonars, Nakat ECM suite

Complement

55

Diving depth operational, m

170



Standard scale images


1965
1965


Graphics





Project history

Former Soviet Project 613 submarines.

Modernizations

none

Naval service

In 2005 all four submarines were no longer operational but can be used as stationary training boats, battery recharging stations etc.
