AMNOK corvettes (2015-2016)
2015
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| i | Najin SY | 2015 | in service (2019) | ||||
| ii | Nampo SY | 2016 | in service (2019) |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 1300 |
| Length, m | 77.0 |
| Breadth, m | 8.00 |
| Draught, m | |
| No of shafts | |
| Machinery | 2 diesels |
| Power, h. p. | |
| Max speed, kts | |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | |
| Armament | 2 x 4 KN-19 Kumsong-3 SSM (8 KN-19), 1 x 6 FN-6? SAM, 1 x 1 - 76/59 HJ-26?, 2 x 2 - 30/71 AK-230, 2 x 2 - 533 TT, 4 x 5 RBU-1200 ASWRL |
| Electronic equipment | nav., surf. search, air search, MR-104 Rys' radars, sonar, ECM suite, decoy RL |
| Complement |
Standard scale images
2015
Graphics
2015
Project history
New corvettes of indigenious construction, first observed in 2015.
Modernizations
None.
Naval service
No significant events.
