NAVYPEDIA


Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
	381		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	382		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	383		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	384		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	385		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	386		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	387		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	388		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	389		Wuzhou SY, China			1963-69 // 1967-69	discarded late 1990s
	390		Wuzhou SY, China			1963-69 // 1967-69	discarded early 2000s
	391		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	392		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	393		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	394		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)
	395		Wuzhou SY, China			1963-69 // 1967-69	in service (2019)

Technical data

Displacement standard, t	123
Displacement full, t	135
Length, m	38.8
Breadth, m	5.41
Draught, m	1.55
No of shafts	4
Machinery	2 M-50F-4 diesels, 2 12D6 diesels
Power, h. p.	2400+1820=4200
Max speed, kts	28.5
Fuel, t	diesel oil
Endurance, nm(kts)	750(16.5)
Armament	2 x 2 - 37/63 type 61, 2 x 2 - 25/80 type 61M, 2 x 5 type 81 ASWRL (on some), 4 DC, 10 mines (overload)
Electronic equipment	Reya or type 351 radar, Tamir-11 sonar
Complement	36

Standard scale images

Graphics

Project history

Chinese Type 062 coastal patrols.

Modernizations

none

Naval service

One boat was damaged in 1988, one in 1990 and one in 1998.
