        12-go 1915 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
第10号艦 [10-go], 11.1924- 波3 [HA3]		397	Vickers, Barrow, UK / Kure K K	9/1910	4.3.1911	8/1911	stricken 12.1928
第11号艦 [11-go], 11.1924- 波4 [HA4]		398	Vickers, Barrow, UK / Kure K K	9/1910	18.3.1911	8/1911	stricken 12.1928
第12号艦 [12-go], 11.1924- 波5 [HA5]		399	Vickers, Barrow, UK / Kure K K	9/1910	27.3.1911	8/1911	stricken 12.1928

Technical data

Displacement standard, t
Displacement normal, t	291 / 326
Length, m	40.1 pp 43.3 oa
Breadth, m	4.10
Draught, m	3.40
No of shafts	1
Machinery	1 16-cyl Vickers petrol engine / 1 electric motor
Power, h. p.	600 / 300
Max speed, kts	12 / 8.5
Fuel, t	petrol 15.5
Endurance, nm(kts)	660(12) / 60(4)
Armament	2 - 450 TT (bow, 2), 1 x 1 - 6.5/115
Complement	25
Diving depth operational, m	30

Standard scale images

Graphics

Project history

Vickers C(2) type. Built in Britain by Vickers and assembled in Japan from sections. The same type as British C type. Single-hulled. Japanese did not have experience of designing of modern submarines, and it was necessary to be content with already hopelessly out-of-date design.

Modernizations

None.

Naval service

No significant events.
