Ishikari 2003

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
いしかり [Ishikari]	DE226		Mitsui, Tamano	17.5.1979	18.3.1980	28.3.1981	stricken 10.2007

Technical data

Displacement standard, t	1200
Displacement full, t	1450
Length, m	84.5
Breadth, m	10.0
Draught, m	3.50 mean hull
No of shafts	2
Machinery	CODOG: 1 Kawasaki-Rolls-Royce Olympus TM-3B gas turbine / 1 Mitsubishi 6DRV35/44 diesel
Power, h. p.	28390 / 5000
Max speed, kts	25
Fuel, t	diesel / gas turbine oil
Endurance, nm(kts)
Armament	2 x 4 Harpoon SSM (8 RGM-84C), 1 x 1 - 76/62 OTO-Melara Compact, 2 x 3 - 324 type 68 TT, 1 x 4 - 375 type 71 ASWRL
Electronic equipment	OPS-19B, OPS-28, FCS-2-21B radars, OQS-4 (SQS-36D(J)) sonar, NOLQ-6C, OLT-3, OLR-9B ECM suites, 2x Mk 36 SRBOC decoy RL, OYQ-5 CCS
Complement	90

Standard scale images

Graphics

Project history

Two units of the Ishikari class were originally authorised, one in 1977-78 and the second n 1979-80, but only one was built. As many as twenty were planned. This design was smaller and less sophisticated than the preceding Chikugo class, but too much seems to have been attempted on the displacement - hence the curtailment of the programme, and the evolution of the Yubari design.

Modernizations

None.

Naval service

No significant events.
