NARUMI river gunboat (1921 / 1943)





Narumi

Ships


Name No Yard No Builder Laid down Launched Comp Fate
鳴海 [Narumi] (ex-Ermanno Carlotto)     Shanghai Dock, China   19.6.1918 2/1921 // 15.10.1943 surrendered 8.1945, to China 1946 (錢坤 [Kiang Kun])


Technical data


Displacement normal, t218
Displacement full, t
Length, m

48.8

Breadth, m

7.50

Draught, m

0.91

No of shafts

2

Machinery

2 VTE, 2 Yarrow boilers

Power, h. p.

1100

Max speed, kts

14

Fuel, toil 56
Endurance, nm(kts)
Armament

2 x 1 - 76/40 3-shiki, 6 x 1 - 7.7/80

Complement44


Standard scale images


<i>Narumi</i> 1943
Narumi 1943


Graphics


<i> Narumi</i>
Narumi


Project history

Italian river gunboat Ermanno Carlotto was scuttled by crew 9.9.1943 in Shanghai, salvaged by Japanese and entered service as Narumi 15.10.1943.

Modernizations

1945: disarmed.

Naval service

Narumi was damaged 15.1.1945 by US Army aircraft near Hankow, disarmed 1945 (guns were used ashore) and surrendered in August, 1945.
