Atami

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
熱海 [Atami]			Fujinagata, Osaka	11.1928	30.3.1929	6.1929	surrendered 8.1945, to China 8.1945 (永平 [Yung Ping])
二見 [Futami]			Fujinagata, Osaka	6.1929	20.11.1929	2.1930	surrendered 8.1945, to China 8.1945 (永安 [Yung An])

Technical data

Displacement standard, t	206
Displacement full, t	249
Length, m	45.3 pp 46.3 oa
Breadth, m	6.30
Draught, m	0.92
No of shafts	2
Machinery	2 2-cyl compound VE, 2 Kampon boilers
Power, h. p.	1300
Max speed, kts	16.7
Fuel, t	oil 53
Endurance, nm(kts)
Armament	1 x 1 - 76/23 41-shiki, 1 x 1 - 13.2/76, 5 x 1 - 7.7/80
Complement	77

Standard scale images

Graphics

Project history

River gunboats of Atami class were intended for service on Chinese rivers. Ships had  similar characteristics and outwardly resembled predeccessors. Built under the 1923 programme.

Modernizations

1940, both: - 1 x 1 - 76/23, 1 x 1 - 13.2/76, 5 x 1 - 7.7/80; + 1 x 1 - 76/40 11-shiki, 5 x 1 - 25/60 96-shiki

1945, both: disarmed

Naval service

In 1945 both gunboats transferred their guns to coastal batteries.

In 1945 China received Atami and Futami.
