CG123 2010

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
CG121-124	SeaArk Marine, Monticello, USA: CG121-124	1992: CG121-123 1994: CG124	None	None	in service (2020): CG121-124

Technical data

Displacement standard, t	11
Displacement full, t	15
Length, m	11.1 pp 12.2 oa
Breadth, m	3.86
Draught, m	0.69
No of shafts	2
Machinery	2 Caterpillar 3208TA
Power, h. p.	690
Max speed, kts	28
Fuel, t	diesel oil
Endurance, nm(kts)	600(18)
Armament	2 x 1 - 7.6/90
Electronic equipment	Raytheon radar
Complement	4

Graphics

Project history

SeaArk 'Dauntless' design. Aluminium consruction.

Modernizations

None.

Naval service

No significant events.
