SIRENA medium submarines (1933 - 1934)





Sirena 1942

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Ametista     OTO, Muggiano 9.1931 26.4.1933 4.1934 scuttled 12.9.1943
Anfitrite     CRDA, Monfalcone 7.1931 5.8.1933 3.1934 sunk 6.3.1941
Diamante     Tosi, taranto 5.1931 21.5.1933 11.1933 sunk 20.6.1940
Galatea     CRDA, Monfalcone 7.1931 5.10.1933 6.1934 discarded 2.1948
Naiade     CRDA, Monfalcone 5.1931 27.3.1933 11.1933 sunk 14.12.1940
Nereide     CRDA, Monfalcone 5.1931 25.5.1933 2.1934 sunk 13.7.1943
Ondina     CRDA, Monfalcone 7.1931 2.12.1933 9.1934 sunk 11.7.1942
Rubino     CNQ, Fiume 9.1931 29.3.1933 3.1934 sunk 29.6.1940
Sirena     CRDA, Monfalcone 5.1931 26.1.1933 10.1933 scuttled 9.9.1943
Smeraldo     Tosi, Taranto 5.1931 23.7.1933 11.1933 sunk about 16.9.1941
Topazio     CNQ, Fiume 9.1931 15.5.1933 4.1934 sunk 12.9.1943
Zaffiro     OTO, Muggiano 9.1931 28.6.1933 6.1934 sunk probably 9.6.1942


Technical data


Displacement standard, t617 - 623
Displacement normal, t

680 / 837

Length, m

60.2

Breadth, m

6.45

Draught, m

4.70

No of shafts

2

Machinery

2 Fiat diesels / 2 CRDA electric motors

Diamante, Rubino, Smeraldo, Topazio: 2 Tosi diesels / 2 Marelli electric motors

Power, h. p.

1200 / 800

Max speed, kts

14 / 7.7

Fuel, t

diesel oil 80

Endurance, nm(kts)2280(12) / 72(4)
Armament

1 x 1 - 100/47 OTO 1931, 2 x 2 - 13.2/76, 6 - 533 TT (4 bow, 2 stern, 12)

Electronic equipmenthydrophone
Complement

45

Diving depth operational, m80


Standard scale images


<i>Ametista</i> 1940
Ametista 1940


Graphics


<i>Sirena</i> 1942
Sirena 1942
<i>Topazio</i> 1941
Topazio 1941


Project history

Development of 600t Argonauta class, with a little larger displacement and changed hull form, become more shortly and more widely. The out-of-date 102mm/35 gun was replaced by more modern 100mm/47. In remaining they differed from predecessors a little.

Modernizations

None.

Naval service

Diamante was sunk 20.6.1940 near Tobruk by British submarine Parthian. Rubino was sunk 29.6.1940 in Ionian sea by British aircraft. Naiade was sunk 14.12.1940 near Bardia by DCs of British destroyers Hereward and Hyperion. Anfitrite was sunk 6.3.1941 off Crete by DCs and gunfire of British destroyer Greyhound. Zaffiro was lost in June, 1942, probably, sunk 9.6.1942 by British aircraft. Ondina was sunk 11.7.1942 near Beirut by South African armed whalers Protea and Southern Maid. Nereide was sunk 13.7.1943 near Augusta by DCs and gunfire of British destroyers Echo and Ilex. Smeraldo was lost in September, 1943 in Mediterranean sea by unknown reason. Sirena was scuttled by crew 9.9.1943 in La Spezia harbour. Topazio was erroneously sunk 12.9.1943 at SE coast of Sardinia by British aircraft. Ametista was scuttled by crew 12.9.1943 near Ancona.
