Keshet 2006

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
רומח [Romah]			Israeli SY, Haifa		30.10.1981	11/1981	in service (2019)
קשת [Keshet]			Israeli SY, Haifa		10.1982	11/1982	in service (2019)

Technical data

Displacement standard, t
Displacement full, t	490
Length, m	58.2 wl 61.7 oa
Breadth, m	7.62
Draught, m	2.78
No of shafts	4
Machinery	4 MTU 16V956 TB91 diesels
Power, h. p.	14000
Max speed, kts	31
Fuel, t	diesel oil
Endurance, nm(kts)	4000(17)
Armament	2 x 2 Harpoon SSM (4 RGM-84A), 6 x 1 Gabriel Mk 2 SSM (6 Gabriel Mk 2), 1 x 1 - 76/62 OTO-Melara Compact, 1 x 6 - 20/76 Mk 15 Phalanx, 2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90
Electronic equipment	TH-D1040 Neptune, RTN-10X Orion radars, MN-53 ECM suite, Deseaver 1x 45-tube, 4x 24-tube, 4x 1-tube decoy RL
Complement	45

Standard scale images

Graphics

Project history

Sa'ar 4.5 class. Lengthened Reshef class hull for additional armament or helicopter facilities. Romah and Keshet have additional armament.

Modernizations

1990s, both: - MN-53 ECM suite; + NS-9003, NS-9005, NATACS ECM suites

2000, Romah; 2001, Keshet: - 2 x 2 Harpoon SSM (4 RGM-84A), RTN-10X Orion radars; + 2 x 2 Harpoon SSM (4 RGM-84C), 4 x 8 Barak SAM (VLS, 32 Barak), 2 x 1 - 12.7/90, 2x EL/M-2221 radars, MSIS e/o system

Naval service

No significant events.
