1998

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
37 units presumably: 850-875 900-910	Sewart Seacraft, Berwick, USA: 12 units Israeli Aircraft Industries, Be'er Sheva: 22 units	1973-1977: 34 units	none	Nicaragua, 1978: 4 units (GC10-13) Argentina, 1978: 4 units (Baradero, Barranqueras del Uruguay, Clorinda, Concepción) Fiji, 1991: 4 units (Vai, Ogo, Saku, Saqa) Chile, 1991: 6 units (Grumete Venanzio Díaz, Grumete Luciano Bolados, Grumete Santiago Salinas, Grumete Blas Segundo Tellez, Grumete Juan Bravo, Grumete David Campos) Chile, 1995: 4 units (Grumete Samuel Machado, Grumete Rudincido Troncoso, Grumete Domingo Johnson, Grumete Manuel Hudson) Nicaragua, 1996: 3 units (GC201, 203, 305)	2010-2014: 902, 905, 906, 909, 910 2015-2017: 850, 851, 853, 854, 860-862, 864, 865, 868, 873

Technical data

Displacement standard, t	25
Displacement full, t	35
Length, m	19.8
Breadth, m	5.80
Draught, m	0.80
No of shafts	2
Machinery	2 General Motors Detroit Diesel 12V71TI diesels
Power, h. p.	960
Max speed, kts	25
Fuel, t	diesel oil
Endurance, nm(kts)	1200(17)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90 some units: 2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90, 2 - 324 TT, 2 DCR
Electronic equipment	Decca 926 or Decca Super 101 Mk 3 radar some units: Decca 926 or Decca Super 101 Mk 3 radar, sonar
Complement	6

Standard scale images

Graphics

Project history

Aluminium construction. Can be carried by truck.

Modernizations

None.

Naval service

No significant events.
