No223 large patrol craft (1965)
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
223, 224 |
345 Yd, Yaroslavl' or Sosnovka Yd, USSR: 223, 224 |
1965: 223, 224 |
223 (1-2/1991), 224 (1-2/1991) |
none |
none |
Technical data
| Displacement standard, t | 86 |
|---|---|
| Displacement full, t | 99 |
| Length, m | 29.9 |
| Breadth, m | 5.98 |
| Draught, m | 1.52 |
| No of shafts | 2 |
| Machinery | 2 M-50F-4 diesels |
| Power, h. p. | 2400 |
| Max speed, kts | 22 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 550(14) |
| Armament | 1 x 2 - 25/82 2M-3M, 1 x 2 - 12.7/79 |
| Electronic equipment | Stvor or Donets-2 radar |
| Complement | 15 |
Standard scale images
No223 1970
Graphics
Project history
Soviet multipurpose boats of Project 368, patrol variant T368.
Modernizations
None.
Naval service
Both craft were lost during Desert Storm operation in 1991.
