NAVYPEDIA


Kasturba Gandhi model

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
कस्तूरबा गाँधी [Kasturba Gandhi]	231		Goa SYd		6.7.2005	28.10.2005	in service (2019)
अरुणा असफ अली [Aruna Asaf Ali]	232		Goa SYd		20.10.2005	28.1.2006	in service (2019)
सुभद्रा कुमारी चौहान [Subhadra Kumari Chauhan]	233		Goa SYd		30.12.2005	28.4.2006	in service (2019)
मीरा बहिन [Meera Behan]	234		Goa SYd		28.1.2006	25.7.2006	in service (2019)
सावित्री बाई पहले [Savitri Bai Phule]	235		Goa SYd		28.4.2006	28.10.2006	in service (2019)

Technical data

Displacement standard, t	235
Displacement full, t	260
Length, m	43.5 wl 48.1 oa
Breadth, m	7.50
Draught, m	2.00 mean hull
No of shafts	3 waterjets
Machinery	3 MTU 16V4000 M90 diesels
Power, h. p.	11100
Max speed, kts	35
Fuel, t	diesel oil
Endurance, nm(kts)	1500
Armament	1 x 1 - 30/80 Medak CRN-91, 2 x 1 - 7.6/90
Electronic equipment	Bharat 1245 radar
Complement	35

Standard scale images

Graphics

Project history

Sarojini Naidu with reduced radar signature.

Modernizations

None.

Naval service

No significant events.
