NAVYPEDIA


1977

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
प्रचंड [Prachand]	K90		Vympel, Rybinsk, USSR			17.2.1976	stricken 12.1999
प्रलय [Pralaya]	K91		Vympel, Rybinsk, USSR			17.2.1976	stricken 6.2001
प्रताप [Pratap]	K92		Vympel, Rybinsk, USSR			17.2.1976	stricken 5.1996
प्रबल [Prabal]	K93		Vympel, Rybinsk, USSR			17.2.1976	stricken 12.1999
चपल [Chapal]	K94		Vympel, Rybinsk, USSR			4.11.1976	stricken 5.2005
चमक [Chamak]	K95		Vympel, Rybinsk, USSR			4.11.1976	stricken 5.2005
चटक [Chatak]	K96		Vympel, Rybinsk, USSR			9.2.1977	stricken 5.2005
चराग [Charag]	K97		Vympel, Rybinsk, USSR			17.10.1977	stricken 5.1996

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate प्रचंड [Prachand] K90   Vympel, Rybinsk, USSR     17.2.1976 stricken 12.1999 प्रलय [Pralaya] K91   Vympel, Rybinsk, USSR     17.2.1976 stricken 6.2001 प्रताप [Pratap] K92   Vympel, Rybinsk, USSR     17.2.1976 stricken 5.1996 प्रबल [Prabal] K93   Vympel, Rybinsk, USSR     17.2.1976 stricken 12.1999 चपल [Chapal] K94   Vympel, Rybinsk, USSR     4.11.1976 stricken 5.2005 चमक [Chamak] K95   Vympel, Rybinsk, USSR     4.11.1976 stricken 5.2005 चटक [Chatak] K96   Vympel, Rybinsk, USSR     9.2.1977 stricken 5.2005 चराग [Charag] K97   Vympel, Rybinsk, USSR     17.10.1977 stricken 5.1996

Technical data

Displacement standard, t	192
Displacement full, t	243
Length, m	38.6
Breadth, m	7.60
Draught, m	2.00
No of shafts	3
Machinery	3 M-504B diesels
Power, h. p.	15000
Max speed, kts	42
Fuel, t	diesel oil
Endurance, nm(kts)	1620(15)
Armament	4 x 1 P-15U SSM (4 P-15U), 2 x 2 - 30/71 AK-230
Electronic equipment	MR-101 Rangout, MR-104 Rys' radars
Complement	29

Standard scale images

Graphics

Project history

Soviet project 205ER.

Modernizations

None.

Naval service

No significant events.
