Óðinn 1967

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Óðinn			Ålborg Vaerft, Denmark	1.1959	9.1959	1/1960	stricken 2006

Technical data

Displacement standard, t	910
Displacement full, t	1000
Length, m	63.7 oa 56.6 pp
Breadth, m	10.0
Draught, m	4.80
No of shafts	2
Machinery	2 Burmeister & Wain diesels
Power, h. p.	5050
Max speed, kts	18
Fuel, t	diesel oil
Endurance, nm(kts)	10000(18)
Armament	1 x 1 - 57/40 Mk 6
Electronic equipment	2x radars
Complement	19

Standard scale images

Graphics

Project history

Patrol vessel.

Modernizations

1975: + hangar, helicopter deck, 1 helicopter, antirolling tanks were fitted

1989: - helicopter; + articulated crane for RIB, RIB

1990: - 1 x 1 - 57/40, 2 radars; + 1 x 1 - 40/60 Mk 3, 2 Sperry Rasterscan radars

Naval service

No significant events.
