ANTIPLIARCHOS LASKOS patrol motor gunboats (1944-1945/1947)





Antipliarchos Pezopoulos 1973

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Πλωτάρχης Αρσλάνογλου [Plotarchis Arsanoglou] (ex-PGM25) P14   Consolidated SB, New York, USA 7.1944 16.9.1944 2.1945 // 8.1947 discarded 1979
Αντιπλοίαρχος Λάσκος [Antipliarchos Laskos] (ex-PGM16) P53   Defoe, Bay City, USA 10.1943 19.12.1943 10.1944 // 8.1947 discarded 1971
Πλωτάρχης Μελετόπουλος [Plotarchis Meletopoulos] (ex-PGM22) P57   Consolidated SB, New York, USA 5.1944 25.6.1944 12.1944 // 8.1947 discarded 1971
Πλωτάρχης Μπλέσσας [Plotarchis Blessas] (ex-PGM28) P61   Consolidated SB, New York, USA 6.1944 19.11.1944 4.1945 // 8.1947 discarded 1963
Αντιπλοίαρχος Πεζόπουλος [Antipliarchos Pezopoulos] (ex-PGM21) P75   Consolidated SB, New York, USA 4.1944 25.5.1944 11.1944 // 8.1947 discarded 1977
Πλωτάρχης Χατζηκωνσταντής [PLotarchis Chadzikonstandis] (ex-PGM29) P96   Leatham D. Smith SB, Sturgeon Bay, USA 5.1944 16.7.1944 11.1944 // 8.1947 discarded 1979


Technical data


Displacement standard, t

335

Displacement full, t

439

Length, m

51.8 wl 52.9 oa

Breadth, m

7.06

Draught, m

3.30 full load

No of shafts2
Machinery

2 General Motors diesels

Power, h. p.

2880

Max speed, kts

19

Fuel, tdiesel oil 49
Endurance, nm(kts)3000 (12) - 4800 (12)
Armament

1 x 1 - 76/50 Mk 21, 1 x 2 - 40/60 Mk 1, 6 x 1 - 20/70 Mk 10, 1 x 2 - 60/12 M19 mortar, 2 х 1 - 12.7/90

Electronic equipment

SF or SO or SU radar

Complement59 - 65


Standard scale images


<i>Antipliarchos Laskos </i>1970
Antipliarchos Laskos 1970


Graphics


<i>Antipliarchos Pezopoulos </i>1973
Antipliarchos Pezopoulos 1973


Project history

Former USN PGM9 class patrol vessels.

Modernizations

1963, all survived: - 1 x 2 - 40/60, 2 x 1 - 20/70, 1 x 2 - 60/12 mortar, 2 x 1 - 12.7/90; + 1 x 2 - 20/70 Mk 24, 1 x 24 - 178 Hedgehog Mk 11 ASWRL, 2 DCR, sonar

Naval service

No significant events.
