ACHIMOTA fast attack craft (gun) (1981)
Achimota 2007
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| Achimota | P28 | Lürssen, Vegesack, West Germany | 1978 | 14.3.1979 | 27.3.1981 | in service (2019) | |
| Yogaga | P29 | Lürssen, Vegesack, West Germany | 1978 | 14.3.1979 | 27.3.1981 | in service (2019) |
Technical data
| Displacement standard, t | 380 |
|---|---|
| Displacement full, t | 410 |
| Length, m | 58.1 |
| Breadth, m | 7.62 |
| Draught, m | 2.83 |
| No of shafts | 3 |
| Machinery | 3 MTU 16V538 TB91 diesels |
| Power, h. p. | 10800 |
| Max speed, kts | 30 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | |
| Armament | 1 x 1 - 76/62 OTO-Melara Compact, 1 x 1 - 40/70 Breda-Bofors 564 |
| Electronic equipment | Decca 1226, Triton radars, LIOD e/o system |
| Complement | 40 |
Standard scale images
Achimota 1990
Graphics
Achimota 2007
Project history
Lürssen PB57 type.
Modernizations
None.
Naval service
No significant events.
