1978

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
131.1-131.4 131.401-131.430	Peenewerft, Wolgast: 131.1-131.4, 131.401-131.430	1972: 131.1, 131.2 1973: 131.3 1974: 131.4, 131.401 1975: 131.402-131.413 1976: 131.414-131.427 1977: 131.428-131.430	131.421 (collision 7.6.1986)	none	1972: 131.1, 131.2 1973: 131.3 1982: 131.422 1984: 131.4, 131.401, 131.402, 131.409, 131.413-131.419, 131.425, 131.427-131.430 1989: 131.403-131.407, 131.411, 131.412, 131.420, 131.423, 131.424, 131.426 1990: 131.408, 131.410

Technical data

Displacement standard, t	28
Displacement full, t	35
Length, m	19.0
Breadth, m	4.42
Draught, m	2.33
No of shafts	3
Machinery	3 M-50F3 diesels
Power, h. p.	3600
Max speed, kts	48
Fuel, t	diesel oil
Endurance, nm(kts)	300(48)
Armament	1 x 2 - 23/87 ZU-23-2, 2 - 533 TT, mines
Electronic equipment	TSR-222 radar
Complement	63.1-63.3: 2 others: 3

Standard scale images

Graphics

Project history

Replacement for 'Iltis' and 'Hydra' classes. Aluminium construction. The deck space on both sides of the CT were occupied by removable launchers for KMD type ground mines, which could be replaced by portable windlasses and seats for commandos.

Modernizations

1970s, all: - KSA-5 radar; + TSR-222 radar

Naval service

: No significant events.
