NAVYPEDIA


U151 1917

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Bremen		381/262?	Flensburg SB / Germaniawerft, Kiel	1915	1916	late 1916	sunk early 1917
Deutschland, 2.1917- U155		382/263	Flensburg SB / Germaniawerft, Kiel	1915	28.3.1916	late 1916	to United Kingdom 11.1918
U151 (ex-Oldenburg)		/294	Flensburg SB / Germaniawerft, Kiel	1916	4.4.1917	7.1917	to France 11.1918
U152		/295	Reiherstieg, Hamburg / Germaniawerft, Kiel	1916	20.5.1917	10.1917	to United Kingdom 11.1918
U153		/296	Reiherstieg, Hamburg / Germaniawerft, Kiel	1916	19.7.1917	11.1917	to United Kingdom 11.1918
U154		/297	Reiherstieg, Hamburg / Germaniawerft, Kiel	1916	10.9.1917	12.1917	sunk 11.5.1918
U156		151/298	Atlas Werke, Bremen / Germaniawerft, Kiel	1916	14.4.1917	8.1917	sunk 25.9.1918
U157		/299	Stülcken, Hamburg / Germaniawerft, Kiel	1916	23.5.1917	9.1917	interned 11.1918, to France 2.1919

Technical data

Displacement standard, t
Displacement normal, t	Deutschland, Bremen: 1575 / 1860 U151 - 157: 1512 / 1875
Length, m	65.0
Breadth, m	8.90
Draught, m	5.30
No of shafts	2
Machinery	2 Germania diesels / 2 SSW electric motors
Power, h. p.	Bremen, Deutschland: 800 / 750 U151 - 157: 800 / 800
Max speed, kts	Bremen, Deutschland: 10 / 6.7 U151 - 157: 12.4 / 5.2
Fuel, t	Bremen, Deutschland: diesel oil 200 U151 - 157: diesel oil 285
Endurance, nm(kts)	Bremen, Deutschland: 12000(10) / U151 - 157: 25000(5.5) / 65(3)
Armament	Bremen, Deutschland: unarmed U155: 2 x 1 - 149/37 SK L/40 C/97, 3 x 2 - 500 TT (deck, 24) U151 - 154, 156, 157: 2 x 1 - 105/42 Utof L/45 C/16, 2 x 1 - 88/27 TK L/30 C/08, 2 - 500 TT (bow, 18)
Complement	56 + 20 prize crew
Diving depth operational, m	50

Standard scale images

Graphics

Project history

Double-hulled. This class of submarine cruisers was initially designed as submarine freighters with names. The Deutschland made one visit to the USA which was more a propaganda than a commercial success; her sister Bremen was lost during her first voyage; the third unit Oldenburg was never commissioned as a submarine freighter, since by then the USA had entered the war. From February 1917 they were converted to submarine cruisers, the other units of this type being built as such from keel up. U155 had originally 6 aw TT (3x2) on the deck, reloaded only in surfaced position.

Modernizations

1918, U155: - 3 x 2 - 500 TT; + 2 - 500 TT (bow, 18)

Naval service

U154 was torpedoed by British submarine E35 11.5.1918 in the Atlantic. Bremen was lost by unknown cause, probably mined off Orkney Islands in her first voyage early 1917. U156 was mined on the Northern barrage 25.9.1918 in the North Sea.
