BRUMMER minelayer (1934 / 1940)





Brummer

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Albatros (ex-Olav Tryggvason), 5.1940- Brummer   119 Marinen Hovedverft, Horten, Norway 1931 21.12.1932 21.6.1934 // 11.4.1940 damaged 13.4.1945, never repaired


Technical data


Displacement standard, t1763
Displacement full, t1860
Length, m

92.5 wl 97.3 oa

Breadth, m

11.5

Draught, m

3.60 normal load 4.03 deep load

No of shafts

2

Machinery

2 sets Laval geared steam turbines, 3 water-tube boilers / 2 Sulzer diesels

Power, h. p.

6000 / 1400

Max speed, kts

14 / 22

Fuel, toil + diesel oil 200
Endurance, nm(kts)3000(14)
Armament4 x 1 - 120/41 Bofors, 1 x 2 - 37/80 SK C/30, 4 x 1 - 20/65 C/38, 280 mines
Complement168


Standard scale images


<i>Brummer</i> 1943
Brummer 1943


Graphics


<i>Brummer</i>
Brummer
<i>Brummer</i>
Brummer


Project history

Former Norwegian minelayer Olaf Tryggvason, 9.4.1940 captured by German troops at Horten, 11.4.1940 renamed Albatros and 16.5.1940 Brummer. Ship was rearmed before commission (originally carried 4 120mm, 1 76mm, and 2 40mm guns). According to some information, instead of 105mm had 127mm/45 guns.

Modernizations

Summer 1943: - 4 x 1 - 120/44; + 3 x 1 - 105/42 SK C/32, 6 x 1 - 20/65 C/38.

Naval service

Brummer was destroyed 3.5.1945 in dock during US air raid to Kiel.
