Elbe Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Elbe		119	MW Wilhelmshaven	1929	24.1.1931	11.1931	surrendered 5.1945, to Soviet Union (Терек [Terek])
Weser		120	MW Wilhelmshaven	1929	24.1.1931	11.1931	surrendered 5.1945, BU 1954

Technical data

Displacement standard, t	820
Displacement full, t	870
Length, m	54.3 wl 58.0 oa
Breadth, m	8.50
Draught, m	3.70
No of shafts	2
Machinery	2 diesels
Power, h. p.	1600
Max speed, kts	14
Fuel, t	diesel oil 87
Endurance, nm(kts)	10500(11)
Armament	1 x 1 - 88/42 TK L/45 C/14, 1 x 1 - 37/80 SK C/30
Complement	65

Standard scale images

Graphics

Project history

Fishery protection ships, built on order of Ministry of Finance. With war beginning were re-classified to patrols.

Modernizations

None.

Naval service

Elbe was transferred on reparations to the USSR as Terek.
