V125 large torpedo boats (1917 - 1918)





V125 1917

Ships


Name No Yard No Builder Laid down Launched Comp Fate
V125   470 Vulcan, Stettin 1916 18.5.1917 8.1917 interned 11.1918, to United Kingdom 7.1919
V126   471 Vulcan, Stettin 1916 30.6.1917 9.1917 interned 11.1918, to France 7.1919
V127   472 Vulcan, Stettin 1916 28.7.1917 10.1917 interned 11.1918, to Japan 7.1919
V128   473 Vulcan, Stettin 1916 11.8.1917 11.1917 interned 11.1918, to United Kingdom 7.1919
V129   474 Vulcan, Stettin 1916 19.10.1917 12.1917 interned 12.1918, scuttled 21.6.1919
V130   475 Vulcan, Stettin 1916 20.11.1917 2.1918 to France 8.1920 (Buino)
V140   99 Vulcan, Hamburg 1917 22.12.1917 11.1918 discarded 11.1919, wrecked 8.12.1920
V141   100 Vulcan, Hamburg 1917 26.3.1918 --- sold incomplete 11.1919
V142   493 Vulcan, Stettin 1917 25.9.1918 --- sold incomplete 11.1919
V143   494 Vulcan, Stettin 1917 25.9.1918 --- sold incomplete 11.1919
V144   495 Vulcan, Stettin 1917 10.10.1918 --- sold incomplete 11.1919


Technical data


Displacement normal, t

924

Displacement full, t

1188

Length, m

82.0 oa 81.7 wl

Breadth, m

8.32

Draught, m

4.12

No of shafts

2

Machinery

2 AEG-Vulcan steam turbines, 3 Marine boilers

Power, h. p.

23500

Max speed, kts

34

Fuel, t

oil 298

Endurance, nm(kts)

2050(17)

Armament

3 x 1 - 105/42 Utof L/45 C/16, 2 x 2 - 500 TT, 2 x 1 - 500 TT (8), 24 mines

Complement

105



Standard scale images


<i>V125</i> 1918
V125 1918


Graphics


<i>V125</i> 1917
V125 1917


Project history

V125-V130 were the follow-on boats of the 1916 mobilisation type (the first boat being G96).

Modernizations

None.

Naval service

No significant events.
