G101 destroyers (1915)





G101

Ships


Name No Yard No Builder Laid down Launched Comp Fate
G101 (ex-Santiago)   211 Germaniawerft, Kiel 1914 12.8.1914 3.1915 interned 11.1918, scuttled 21.6.1919
G102 (ex-San Luis)   212 Germaniawerft, Kiel 1914 16.9.1914 4.1915 interned 11.1918, scuttled 21.6.1919
G103 (ex-Santa Fé)   213 Germaniawerft, Kiel 1914 14.11.1914 5.1915 interned 11.1918, scuttled 21.6.1919
G104 (ex-Tucuman)   214 Germaniawerft, Kiel 1914 28.11.1914 6.1915 interned 11.1918, scuttled 21.6.1919


Technical data


Displacement normal, t

1116

Displacement full, t1734
Length, m

95.3 oa 94.0 wl

Breadth, m

9.47

Draught, m

3.84

No of shafts

2

Machinery

2 Germania steam turbines, 3 doubled oil-burning boilers

Power, h. p.

28000

Max speed, kts

33.5

Fuel, t

oil 500

Endurance, nm(kts)2420(20)
Armament

4 x 1 - 88/42 TK L/45 C/14, 2 x 2 - 500 TT, 2 x 1 - 500 TT (8), 24 mines

Complement

104



Standard scale images


<i>G101 </i>1918
G101 1918


Graphics


<i>G101</i>
G101


Project history

Ordered for the Argentine Navy with cruising diesels, 10.2cm guns and 53.3cm torpedoes, they were seized by the Imperial German Navy and commissioned on the outbreak of war. Like the B97 class they were referred to as 'destroyers'.

Modernizations

1916, G101, 103, 104: - 4 x 1 - 88/42; + 4 x 1 - 105/43 TK L/45 C/16

1916, G102: - 4 x 1 - 88/42; + 4 x 1 - 105/42 Utof L/45 C/16

Naval service

No significant events.
