TSOTNE DADIANI patrol boats (1962-1963/2000-2002)
Generali Mazniashvili 2002
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
P210 ოტნე დადიანი [Tsotne Dadiani] (ex-Point Countess, ex-WPB82335), 2009- P101 ოტნე დადიანი [Tsotne Dadiani] P211 გენერალი მაზნიაშვილი [Generali Mazniashvili] (ex-Point Baker, ex-WPB82342), 2009- P102 გენერალი მაზნიაშვილი [Generali Mazniashvili] |
USCG Yard, Curtis Bay, USA: P210, 211 |
1962 // 2000: P210 1963 // 2002: P211 |
none |
none |
in service (2020): P101, 102 |
Technical data
| Displacement standard, t | 64 |
|---|---|
| Displacement full, t | 69 |
| Length, m | 25.3 |
| Breadth, m | 5.25 |
| Draught, m | 1.80 |
| No of shafts | 2 |
| Machinery | 2 Caterpillar 3412 V12 diesels |
| Power, h. p. | 1600 |
| Max speed, kts | 23 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1500(8) |
| Armament | 2 x 1 - 12.7/90 |
| Electronic equipment | SPS-73 radar |
| Complement | 8 |
Standard scale images
Tsotne Dadiani 2000
Graphics
Generali Mazniashvili 2002
Project history
Former USCG Point-class cutters, transferred as a gift.
Modernizations
None.
Naval service
No significant events.
