Colonel Djoué Dabany 2000

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Général d'Armée Ba Oumar	P07		CMN, Cherbourg, France	2.7.1986	18.12.1987	6.8.1988	in service (2019)
Colonel Djoué Dabany	P08		CMN, Cherbourg, France	5.1989	29.3.1990	14.9.1990	in service (2019)
Capitaine de Vaisseau Bivigou Nziengu (ex-Le Tapageuse)	P09		CMN, Cherbourg, France	13.8.1985	16.2.1987	11.2.1988 // ---	transfer cancelled 2014

Technical data

Displacement standard, t	371
Displacement full, t	446
Length, m	50.0 pp 54.6 oa
Breadth, m	8.00
Draught, m	2.54 max
No of shafts	2
Machinery	2 SACM-Wärtsilä UD33 V16 M7 diesels
Power, h. p.	8000
Max speed, kts	26
Fuel, t	diesel oil 73
Endurance, nm(kts)	4400(14.5)
Armament	P07: 1 x 1 - 57/70 SAK-57 Mk 2, 1 x 1 - 20/90 GAM-B01 P08: 2 x 1 - 20/90 F2
Electronic equipment	Decca 1226C radar
Complement	25 + 23 passengers

Standard scale images

Graphics

Project history

French 'Super Patra' class. Transfer of the third craft, ex-French La Tapageuse, was cancelled in favor of order of new patrol ship.

Modernizations

None.

Naval service

No significant events.
