Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
X, 2.1911- Dauphin	Q035	Q13	Arsenal de Cherbourg		15.11.1904	1905	stricken 5.1914

Technical data

Displacement standard, t
Displacement normal, t	168 / 179
Length, m	37.0
Breadth, m	3.10
Draught, m	2.40
No of shafts	2
Machinery	2 Panhard et Levassor engines / 2 electric motors
Power, h. p.	260 / 230
Max speed, kts	8.4 / 6.1
Fuel, t	bensoil
Endurance, nm(kts)	170(8.4) / 60(4.5)
Armament	1 - 450 TT (bow), 3 - 450 TC (2 Drzewiecki, 1 aft ext) (6)
Complement	15
Diving depth operational, m	30

Standard scale images

Graphics

Project history

Single-hull steel submarine, designed by M Romazotti. First submarine with two shafts. Estimated cost was 499,400 francs (£19,976).

Modernizations

None.

Naval service

No significant events.
